Features:

Range: 500 - 1750 °C
Sampling rate: 10 samples/s
Resolution 1 °C, measurement uncertainty ±2 °C or better
Reference junction temperature compensation
Stores the last 10 temperature readings
Rechargeable lithium battery for 250 measurements

Technical Data

TEasy-M Immersion Thermometer

Measuring principle:
Microcontroller-based plateau interpretation

Measure range:
500 ... 1750 °C
(Type B up to 1820 °C,
Type K 200 up to ≤ 1350 °C)

Start temperatur:
800 °C (Standard; adjustable Via admixture)

Sampling frequency:
10 measurements /s

Temperatur plateau:
Tolenrance 5 °C
(Standard; adjustable via software)
Plateau length, 2 s
(Standard; adjustable via software)

Maximale Measurering time:
6 s, after preservation of the start temperature
(Standard; adjustable via software - Typ K up to 102 s

Internal memory:
stores the last 10 valid measurements (0-9)

Automatically switch off:
1 min after last operation

Accuracy:
2 °C in the complete measuring range

Thermocouple types:
Type S (Pt-10%Rh/Pt)
500 ... 1750 °C
Type B (Pt-30%Rh/Pt6%Rh)
500 ... 1820 °C
Type R (Pt-13%Rh/Pt)
500 ... 1750 °C
Type K (NiCr/Ni)
200 ... 1350 °C

Ambient temperature:
0 ... 50 °C

Operating data:
Power supply 7,2 V DC
(via rechargeable battery) d. h. approx. 250 measurement
10 h operating time per charging

Display:
4 digit, digit height 14 mm
Following information are reported:
Measuring circuit open = "oPEn"
Probe connected = "0000"
Temperature measurement is running= "Temperatur-Value"
Temperatur measurement end= "measured temperature"

Status indication:
Green LED "READY": "Probe connected, ready to measure"
Yellow LED "MEASURE": "Measurement is running"
Red LED "COMPLETE": Measurement complete"

Piezos buzzer:
approx. 2 s signal tone: "end of the measurement"

Downloads:

TEasy-M_e.pdf
PDF [287KB]

print page |

set bookmark

Other Products

TEasy-M Immersion Thermometer

TEasy-M, a portable immersion thermometer with microprocessor technology, is especially suitable for on-the-spot temperature checks of molten metal at furnaces, coquilles, and casting ladles. This portable, compact device enables quick and precise measurements up to 1820 °C. Due to its low current drain and the automatic switch-off feature, TEasy-M can produce up to 250 temperature readings per battery charge.
